Tuxedo FP12K-K 12,000 lb Four Post Lift – Cable Driven
Tuxedo FP12K-K 12,000 lb Four Post Lift – Cable Driven Original price was: £2,869.51.Current price is: £2,439.09.

TUXEDO FP12K-K 12,000 LB CABLE DRIVEN 4 POST LIFT

Original price was: £1,367.09.Current price is: £1,162.02.

SKU: SKU_1775324201203_302 Category:
Description

Features & Benefits 12,000 lb. Capacity Heavy Duty, Commercial Grade Extra Tall, Extra Wide & Extra Long Built-In Slip Plates & Alignment Turntables Included Multiple Positions for Turntable Placement Runway Covers Included (when Turntables are Removed) Air Operated Single Point Lock Release (External Air Supply Required) Lock Ladder Design Double Lock Safety System Powder Coat Finish Steel Approach Ramps Included Additional Drive off Ramps Available (Sold Separately) Runway Extensions Available (Sold Separately) Mounting Hardware Included 220volt/1phase Electric Operation (Requires a 30amp Breaker) 5 yr Structural – 2 yr Hydraulic Warranty   TUXEDO FP12K-K 12,000 LB Specifications Capacity 12,000 lb. Lifting Height 77 3/4″ (6′ 5 3/4″) Overall Width Of Columns (Without Motor) 126 1/4″ (10′ 6 1/4″) Overall Width Of Columns (With Motor) 135 1/4″ (11′ 3 1/4″) Overall Length With Approach Ramp 236 1/2″ (19′ 8 1/2″) Length Between Columns 183 1/4″ (15′ 3 1/4″) Runway Length 194 1/2″ (16′ 2 1/2″) Runway Width 20″ Thickness Of Runway 7 1/2″ Width Between Runways 43 1/4″ (w/ Rail 39 3/4″) Outside Runway To Outside Runway 83 1/4″ (6′ 11 1/4″) Clearance Under Runways 70 1/4″ (5′ 10 1/4″) Clearance Between Columns 112 5/8″ (9′ 4 5/8″) Height Of Columns 89 3/4″ (7′ 5 3/4″) Maximum Wheel Base 185″ (15′ 5″) Drive Thru 98″ (8′ 2″) Air Requirement 85-115 PSI (EXTERNAL AIR SUPPLY REQUIRED) Motor/Electrical Requirement 220 volt single (1) phase.A 30-amp breaker is recommended Oil Requirement 3-5 GallonsAW32/AW46 (NOT INCLUDED)
